How to Pack Products Correctly for Safe Delivery — A Practical Guide for Indian Sellers
Most product damage in transit is not caused by rough couriers or bad roads. It is caused by incorrect packing at the source. The product was put in the wrong box. Or the right box but with too much empty space inside. Or the right box but sealed with a single strip of tape that split open on the first sorting belt it touched.
Good packing is a learnable skill with clear rules. Follow them consistently and damage rates fall, returns drop, customers are happier, and the business saves money. This guide covers every step — from choosing the right box to sealing the last flap — for Indian sellers shipping through courier and logistics networks.
At a Glance
Safe delivery comes down to six steps: choose the right box, reinforce the base, cushion the base layer, wrap the product, fill all voids, and seal correctly. Each step has a correct method and a common mistake. Getting all six right reduces transit damage to near zero for most product categories.
Step 1 — Choose the right box
The box must be the right size and the right strength for the product being shipped. Neither too big nor too small.
Do this:
- Measure your product's Length × Width × Height in centimetres
- Add 2–3 cm on each side for cushioning clearance
- Choose 3-ply for lightweight, non-fragile, short-haul products
- Choose 5-ply for heavy, fragile, or long-distance shipments
- Use a new or structurally sound box every time
Avoid this:
- Using a box much larger than the product — creates product movement and wasted filler cost
- Reusing damaged, damp, or previously crushed boxes — structural integrity is compromised
- Forcing a product into a box that is too small — creates pressure on the product and fails the box
- Using 3-ply for heavy or fragile products on long-distance routes
Step 2 — Reinforce the box base before packing
The base of the box takes the most stress — from the product's weight sitting on it and from compression in delivery vehicles and sorting facilities. Reinforce it before anything goes inside:
- H-tape the base flaps — apply tape across the centre seam and extend it 5–8 cm down both sides in an H-pattern before closing the base
- For heavy products over 5 kg, apply a double layer of tape on the base or cross-tape the full base panel for maximum load distribution
- Never use a single centre-strip of tape on the base — it splits under sustained weight, particularly in warm weather when adhesive softens
- For very heavy products, place a corrugated pad inside the base to distribute load across the board surface before adding cushioning
Step 3 — Prepare a cushioning layer at the base
Before placing the product, put a cushioning layer at the bottom of the box. This absorbs the first impact if the box is dropped on its base — which happens frequently in courier sorting facilities during high-volume processing periods.
- Bubble wrap layer: 2–3 cm thick layer at base. Best for fragile products where impact absorption is critical — electronics, glass, ceramics.
- Foam sheet: EPE foam sheet cut to box dimensions. More consistent cushioning than bubble wrap for heavier products that compress bubble wrap flat on impact.
- Crumpled kraft paper: For lighter, non-fragile products. Eco-friendly, cost-effective, and effective for void filling around products that do not need hard impact absorption.
Step 4 — Wrap the product correctly before placing it in the box
Product wrapping is the protective layer between the product surface and the box interior. For most products it is the most important damage-prevention step in the entire packing process:
| Product type | Recommended wrap | Why it matters |
|---|---|---|
| Electronics and glass | Bubble wrap, multiple layers | Impact absorption around fragile surfaces |
| Non-stick cookware | Tissue paper then bubble wrap | Tissue prevents coating scratch before bubble wrap goes on |
| Clothing and fabric | Polybag or tissue wrap | Moisture protection during transit in rain or humidity |
| Oily metal parts | Sealed poly bag first | Prevents oil migration into corrugated board |
| Liquid bottles and jars | Seal cap with tape + polybag | Leakage containment if bottle opens under pressure |
| Flat items — books, prints, art | Rigid board backing on both sides | Prevents bending under courier handling |
| Jewellery and small items | Foam insert or padded pouch first | Prevents small item moving inside larger wrap |
Step 5 — Place the product and fill all voids
Product placement and void filling are where most packing failures happen. The rule is simple: the product must not be able to move inside the box when it is shaken in any direction.
- Place the product in the centre of the box — not pushed against any wall or corner
- Fill all empty space around the product and above it with cushioning material
- Press down gently on the filled box before sealing — if the top closes flat without bowing upward, the fill level is correct
- If the top bows upward under light pressure, remove some fill to avoid creating internal pressure on the product
- Shake the packed box gently before sealing — if you hear or feel movement, add more fill before sealing
The shake test: Hold the sealed box and shake it firmly in all six directions — front and back, left and right, up and down. Any audible or felt movement means the product can move during transit and damage is likely. Reopen and add fill until the shake test is passed.
Step 6 — Seal the box correctly
Incorrect sealing is the single most common packaging failure point in Indian courier shipments. The correct method is H-taping on both top and bottom of the box.
Correct H-tape method:
- Close all top flaps flush — no gaps or overlapping flaps
- Apply tape across the centre flap join from one side of the box to the other
- Extend the tape 5–8 cm down each side of the box, forming the vertical strokes of the H
- Apply a second strip of tape parallel to the first if the box is heavy or the product is fragile
- Confirm all four corners are flush and sealed before handing to courier
Common sealing failures to avoid:
- Single strip of tape across centre only — leaves sides free to pull apart under load
- Taping the top but not reinforcing the bottom — the base carries the full weight in transit
- Using tape that is too narrow — less than 48 mm width tape loses adhesion faster under transit stress
- Applying tape to a dusty, oily, or damp box surface — adhesion fails rapidly
What labelling must go on the outside of the box?
The outside of the box must carry enough information for couriers, recipients, and return handling to work correctly:
- Recipient name, full address with pincode — in clear, large print or on a printed label
- Sender name and return address — essential for failed or undeliverable deliveries
- Courier AWB (airway bill) or tracking label — applied completely flat on a clean surface, not crossing any flap join or tape seam
- "Fragile" sticker on all four sides if the product is breakable — not just on the top panel
- "This side up" arrows if the product must not be inverted — marked on all four vertical sides
- Order ID or invoice reference for your own dispatch tracking and customer service purposes
Special packing considerations for common product categories
Electronics: Bubble wrap minimum 3 layers around the device, foam corner guards, corrugated inner sleeve, 5-ply outer box. Never ship electronics in the retail product box alone — add a corrugated outer shipper box around the retail box.
Liquids and bottles: Seal cap with tape before polybag, place in polybag and seal, pack upright with foam or bubble wrap collar, fill above with cushioning. For multiple bottles, use corrugated dividers to prevent bottle-to-bottle contact.
Clothing and textiles: Polybag to protect from moisture, fold flat, place in flat-pack box with minimal clearance. No heavy cushioning needed — focus is on moisture protection and presentation.
Food and bakery products: Use food-safe inner packaging, ensure product is completely sealed before boxing, add moisture absorbent if needed for dry products. Check courier guidelines for perishable or fragile food items before dispatch.
The complete safe packing checklist
Use this checklist for every outgoing order until correct packing becomes a standardised habit in your operation:
- Box correctly sized — maximum 2–3 cm clearance on each side
- Box is new or structurally sound — no moisture damage or previous crush marks
- Base H-taped on both flaps before packing begins
- Cushioning layer placed at base before product goes in
- Product wrapped appropriately for its surface type and fragility level
- Product centred in box — not touching any wall, corner, or flap
- All voids filled — shake test passed with no audible or felt movement
- Top H-taped on both flaps — tape extends 5–8 cm down each side
- Fragile sticker on all four sides if product is breakable
- Courier AWB label applied flat on clean surface — not over any flap join or tape seam
The bottom line
Correct packing is a discipline, not a talent. The six steps in this guide — right box, reinforced base, base cushion, product wrap, void fill, correct seal — can be learned and standardised in a packing workflow in an afternoon. Once standardised, they eliminate most sources of transit damage without adding significant time or cost to each order.
The foundation of all of this is starting with the right corrugated box. ASPV Industries manufactures corrugated boxes in 3-ply and 5-ply, standard and custom sizes, plain and printed — supplied fresh to order from Mangolpuri, Delhi NCR, with PAN India delivery. Minimum order from 10 units.
To get the right box for your product, call us at 011-41528289 / 9999821806 or visit aspvind.com.
Frequently Asked Questions
What is H-taping and why is it better than single-strip taping?
H-taping applies tape across the centre flap join and extends it 5–8 cm down both sides of the box, forming an H-shape when viewed from above. This seals the flap join at the centre and locks the box sides, preventing flap separation under the two most common transit stresses — compression from stacking and impact from dropping. Single-strip centre-only taping seals the join but leaves the sides free to pull apart under sustained load.
Can I reuse corrugated boxes for outgoing customer orders?
It is not recommended for customer-facing shipments. Reused boxes have reduced structural integrity — moisture exposure and previous stacking loads weaken corrugated board significantly. They also communicate a poor brand impression to customers. For internal stock movement, reused boxes may be acceptable if structurally sound. For outgoing customer orders, always use new boxes.
How much cushioning material is enough?
The shake test is the most practical measure: seal the box and shake it firmly in all six directions. If you can hear or feel the product moving inside, more cushioning is needed. The minimum standard is 2–3 cm of cushioning on all sides of the product — base, top, and all four lateral sides — with no product surface in contact with the box wall.
Where should the courier AWB label be placed on the box?
Apply the AWB label on the largest flat surface of the box — typically the top or one main face. It must lie completely flat, must not cross any flap join or tape seam (which causes tearing during handling), and should not be placed over a corrugated rib that causes bubbling. A smooth, clean, flat surface with the label fully adhered is essential for accurate barcode scanning throughout the courier network.
Does ASPV Industries supply both the boxes and packing accessories like bubble wrap and tape?
ASPV Industries' primary product is corrugated boxes in 3-ply and 5-ply. For complete packing supply needs, contact ASPV Industries directly to discuss what is available and what can be sourced from trusted local suppliers in the Delhi NCR packaging network.
